Truck Electrostatic Grounding Controller

group name: Static Grounding & Bonding Solutions

Min Order: 1 piece

brand name: ALPTEC Static Grounding Solutions Manufacturer

model: Earthing Pro TK

Nearest port for product export: Qingdao Port

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW

Acceptable payment methods: T/T, D/P D/A, PayPal, Westem Union

update time: Mon, 02 Feb 2026 05:34:15 GMT

contact supplier

Paramtents

Ground Resistance Threshold ≤ 10 Ω
Outputs On-off signal,10A 250VAC/5A 30VDC
Operating Temperature -20 °C to +60 °C
Response Time < 1 second
Supply Voltage 85~250 V / 24~48 V
Input Current 90mA
Certification II2(1) G Ex db ia[ia Ga]IIC T6 Gb
Certification II2(1) D Ex ia tb[ia Ga]IIIC T80℃ Db

Packging & Delivery

45cm x34cm x16cm
Min Order1 piece

Briefing

Earthing Pro GE is a true earth verification system designed to prevent ignition risks caused by static electricity during tanker loading and unloading operations.
Unlike conventional grounding monitors that only detect metal contact, Earthing Pro GE actively verifies a genuine low-resistance connection to true earth before enabling operation.

Detailed

Truck Electrostatic Gpuding Controller Earthing Pro TK

1. Introduction

Earthing Pro TK is a true ground verification static control system designed specifically for tank inspection vehicles and inspection operations involving tank trucks.

Unlike basic continuity monitors, Earthing Pro TK verifies whether a tank vehicle is connected to a verified, low-resistance earth, ensuring electrostatic safety before and during inspection activities.

2.Why True Earth Verification Matters？

1.Tank vehicles may appear grounded but are not connected to a true earth .

2.Temporary grounding points may be isolated or ineffective .

3.Static discharge inside or around tanks can ignite flammable vapors .

4.Continuity alone cannot guarantee electrostatic safety.

3.How Earthing Pro TK Works？

1.The grounding clamp is connected to the tank vehicle .

2.Earthing Pro TK measures and verifies the earth reference.

3.The system confirms connection to a true, low-resistance ground .

4.Visual and audible signals indicate grounding status .

5.Alarm is triggered if true ground integrity is lost.

4.Key Features

1.True ground verification technology .

2.Differentiates between false ground and true earth .

3.Continuous monitoring during inspection operations .

4.High-visibility visual and audible alarms.

5.Benefits

1..Prevents false grounding conditions .

2.Enhances safety during tank inspection .

3.Reduces electrostatic ignition risks .

4.Improves inspection reliability and confidence.
